We design and manufacture solvent extraction pilot plants for a wide variety of applications. The following summarizes our full scale solvent extraction pilot plants that we recently manufactured for production of various metals:



Our "Turn-key" Full Scale Solvent Extraction Plants Include:

  • Mixer-Settlers with sealed covers and ventilation header

  • Efficient SX impellers coupled to in-line gear motors

  • Structural support mezzanine with stairs and handrail

  • SX feed polishing filter unit (required to minimize crud)

  • Crud treatment system with recovery of organic phase

  • Feed tanks with level control for SX feed, scrub, & strip

  • Aqueous transfer tanks with organic recovery

  • Organic surge tank with aqueous entrainment recovery

  • Feed pumps with VFD's and calibration tubes

  • Transfer pumps controlled by level switches

  • Organic and aqueous recycle with flow indication

  • Piping, fittings, valves, and process control components

  • Technical consulting during on-site assembly & start-up



Solvent extraction plant for the recovery of uranium.

For more details: Full Scale SX Plant 1

Client:  Fansteel Corporation
Site Location:  Muskogee, OK, USA
Plant Capacity: 200 L/min (org + aq)



SX Kinetics, Inc. designed, manufactured, and installed this solvent extraction plant for the recovery of uranium from tantalum residues.




Solvent extraction plant for the recovery of scandium.

For more details: Full Scale SX Plant 2

Client:  Fansteel Corporation
Site Location:  Muskogee, OK, USA
Plant Capacity: 40 L/min (org + aq)



SX Kinetics, Inc. designed, manufactured, and installed this solvent extraction plant for the recovery of scandium from tantalum residues.




For more details: Full Scale SX Plant 3

Client:  Fansteel Corporation
Site Location:  Muskogee, OK, USA
Plant Capacity: 40 L/min (org + aq)



SX Kinetics, Inc. designed, manufactured, and installed this solvent extraction plant for the recovery of tantalum from tantalum residues.




Solvent extraction plant for the recovery of cobalt.

For more details: Full Scale SX Plant 4

Client:  Cobatec Limited
Site Location:  Cobalt, ON, Canada
Plant Capacity: 133 L/min (org + aq)



SX Kinetics provided the design of the mixer-settlers and supervised the installation of this solvent extraction plant for the recovery of cobalt.



Technical consulting was also provided for plant start-up, training of operators, and preparation of operating procedures.




Mixer-settlers for indium solvent extraction.

For more details: Full Scale SX Plant 5

Client:  AMEC
Site Location:  Lima, Peru
Plant Capacity: 73 L/min (org + Aq)



Designed and manufactured twelve mixer-setters for indium solvent extraction at a zinc refinery in Cajamarquilla, Peru.




Mixer-settlers for cobalt solvent extraction.

For more details: Full Scale SX Plant 6

Client:  Shepherd Chemicals
Site Location:  Norwood, OH, USA
Plant Capacity: 30 L/min (org + Aq)



Designed and manufactured nine mixer-setters for cobalt solvent extraction from dilute nitric acid.
